Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
435
Table 10- 7 PM240-2, IP 20, frame sizes C, 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
...1PC22-2UL0
…1PC22-2AL0
…1PC22-8UL0
...1PC22-8AL0
LO base load power
LO base load input current
LO base load output current
5.5 kW
28.6 A
22.0 A
7.5 kW
36.4 A
28.0 A
HO base load power
HO base load input current
HO base load output current
4 kW
22.8 A
17.5 A
5.5 kW
28.6 A
22.0 A
Fuse according to IEC
Fuse according to UL
3NE 1802-0 (40 A)
50 A Class J
3NE 1817-0 (50 A)
50 A Class J
Power losses without filter
Power losses with filter
0.2 kW
0.2 kW
0.26 kW
0.26 kW
Required cooling air flow
18.5 l/s
18.5 l/s
Weight without filter
Weight with filter
5.0 kg
5.2 kg
5.0 kg
5.2 kg
Table 10- 8 PM240-2, IP20, FSD, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC24-2UL0
…1PC25-4UL0
…1PC26-8UL0
LO base load power
LO base load input current
LO base load output current
11 kW
40 A
42 A
15 kW
51 A
54 A
18.5 kW
64 A
68 A
HO base load power
HO base load input current
HO base load output current
7.5 kW
36 A
35 A
11 kW
43 A
42 A
15 kW
56 A
54 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1818-0 / 63A
60 A
3NE1 820-0 / 80A
70 A
3NE1 021-0 / 100A
90 A
Power loss
0.42 kW
0.57 kW
0.76 kW
Required cooling air flow 55 l/s 55 l/s 55 l/s
Weight 17 kg 17 kg 17 kg
