Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
436 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Table 10- 9 PM240-2, IP20, FSE, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC28-8UL0
…1PC31-1UL0
LO base load power
LO base load input current
LO base load output current
22 kW
76 A
80 A
30 kW
98 A
104 A
HO base load power
HO base load input current
HO base load output current
18.5 kW
71 A
68 A
22 kW
83 A
80 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3 NE1 021-0 / 100A
100 A
3 NE1 224-0 / 160A
150 A
Power loss
0.85 kW
1.20 kW
Required cooling air flow
83 l/s
83 l/s
Weight
26 kg
26 kg
Table 10- 10 PM240-2, IP20, FSF, 3 AC 200 V … 240 V
Article No. - without filter
6SL3210-…
…1PC31-3UL0
…1PC31-6UL0
…1PC31-8UL0
LO base load power
LO base load input current
LO base load output current
37 kW
126 A
130 A
45 kW
149 A
154 A
55 kW
172 A
178 A
HO base load power
HO base load input current
HO base load output current
30 kW
110 A
104 A
37 kW
138 A
130 A
45 kW
164 A
154 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3 NE1 225-0 / 200A
175 A
3 NE1 225 -0 / 200A
200 A
3 NE1 227-0 / 250A
225 A
Power loss
1.44 kW
1.79 kW
2.18 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight 57 kg 57 kg 57 kg
