Commissioning and Diagnostics
5-9
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Device master file
You can download the DDB file
From the Internet at http://www.ad.siemens.de/csi_e/gsd
Integrating the DDB file in the configuration software
The following table 5-4 tells you how to integrate the type file in SIMATIC S7 or
SIMATIC S5 (COM PROFIBUS).
Table 5-4 Integrating the DDB file in the configuration software
Step
STEP 7, as of V3.1 COM PROFIBUS, as of V2.1
1
1 Start STEP 7 and in HWCONFIG call
the Options " Install New GSD
menu command.
Copy the DDB file from the ET 200X to
the COM PROFIBUS directory:
...CPBV..\GSD (default)
Copy the bitmap file to the directory:
...CPBV..\BITMAPS
2 Select the DBB file you want to install
from the following dialog box and
confirm with OK.
Result: The ET 200X is displayed in
the hard-
ware catalog in the PROFIBUS-DP
directory.
Start COM PROFIBUS, and choose the
File " Read GSD File menu command.
Result: The ET 200X is displayed in the
hardware catalog at slave configuration.
3 Configure the ET 200X with STEP 7
(see the integrated help system in
STEP 7).
Configure the ET 200X with
COM PROFIBUS (see the integrated help
system in COM PROFIBUS).
1
If you are using a different configuration software package, refer to its software
documentation
