Siemens SIMATIC ET 200X - Parameters of the EM 143-DESINA for Digital Inputs and Outputs

Technical Specifications
7-67
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Parameters
The following table summarizes the parameters that you can set for the expansion
module.
Table 7-33 Parameters of the EM 143-DESINA for digital inputs and outputs
Parameters
Range Default Area affected
Channel type for I/On
(n= 0...7)
Digital input/
digital output
Digital output
(Channel K0, K2, K4,
K6)
Digital input
(Channel K1, K3, K5,
K7)
Channel
Functional input In
(n=8...15)
Diagnostic input/
diagnostic input with
diagnostic frame/
Input with NC function
Diagnostic input Channel
Response to
CPU/master STOP
Output No current or
voltage
hold last value/
Apply substitute value/
Output No current or
voltage
Channel
Substitute value On
(n=0...7)
0/1 0 Channel
Diagnostic interrupt Yes/no No Module
