Configuration Options
2-2
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Configuring a PROFIBUS-DP network
The principles and rules for configuring a PROFIBUS-DP network are described in
the manual for the DP master.
2.1 Brief overview of the different basic modules
Table 2-1 Brief overview of the different basic modules
Common features
Operation as a DPV0 slave
Operation as a DPV1 slave
Operation as a S7 slave
Diagnostic interrupt
Hardware interrupt
Direct communication
IP 67
BM 141 DI 8 DC 24V
(6ES7 141-1BF12-0XB0)
8 digital inputs
Connectors for the supply and PROFIBUS-DP (copper conductors)
DDB file for DPV1: SI03803D.GSG (as of version 1 of the basic
module)
BM 141 DI 8 DC 24V
ECOFAST
(6ES7 141-1BF01-0AB0)
8 digital inputs
ECOFAST connectors for the supply and PROFIBUS-DP (copper
conductors)
DDB file for DPV1: SI0380D2.GSG (as of version 1 of the basic
module)
BM 141 DI 8 DC 24V
ECOFAST DIAG
(6ES7 141-1BF40-0AB0)
8 digital inputs
ECOFAST connectors for the supply and PROFIBUS-DP (copper
conductors)
Diagnostic interrupt for short circuit and wire break for each channel
Hardware interrupt at rising and falling edge for each channel
DDB file for DPV1: SI0380D3.GSG (as of version 2 of the basic
module)
BM 142 DO 4 DC 24V/2A
(6ES7 142-1BD22-0XB0)
4 digital outputs (2A per output)
Connectors for the supply and PROFIBUS-DP (copper conductors)
DDB file for DPV1: SI03803C.GSG (as of version 3 of the basic
module)
BM 143-DESINA FO
(6ES7 143-1BF00-0XB0)
8 digital inputs or outputs (separately parameterizable as an input or
output), diagnostic input for each channel
ECOFAST connectors for the supply and PROFIBUS-DP (fiber-optic
cables)
DDB file for DPV1: SI03809A.GSG as of version 5 of the basic
module
BM 143-DESINA RS485
(6ES7 143-1BF00-0AB0)
8 digital inputs or outputs (separately parameterizable as an input or
output), diagnostic input for each channel
ECOFAST connectors for the supply and PROFIBUS-DP (fiber-optic
cables)
DDB file for DPV1: SI03809A.GSG (as of version 2 of the basic
module)
