Dimesioned Drawings and Pinouts
C-7
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
C.5 Dimensioned drawing – power module
The diagram below is a dimensioned drawing of a power module. You must add
the length of the coupler plugs/Y connectors and the bending radius of your
particular cables to the specified overall depth. You must add the bending radius of
your particular cable to the specified overall height if the load voltage is looped
through.
60
165
67
87
53.5 28.25
193
95
Figure C-7 Dimensioned drawing – power module
