Technical Specifications
7-86
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Table 7-41 Parameters of analog inputs, Fortsetzung
Expansion modules with Area affectedDefaultRangeParameters
All Trigger for
hardware
interrupt
 Upper limit
value
 Lower limit
value
From 32511 to
–32512
From –32512
to 32511
–
–
Channel
1
For optimum interference suppression of the analog modules as a function of the system frequency
(at 50 Hz, 20 msec reset time; at 60 Hz, 16.7 msec reset time)
Table 7-42 Parameters of analog outputs
Expansion
modules with
AOs
Parameters Range Default Area affected
All Format SIMATIC S7
format/
SIMATIC S5
format
SIMATIC S7
format
Expansion module
All Enable
 Diagnostic
interrupt
Yes/no No
Expansion module
All Diagnosis
 Group
diagnosis
Yes/no No
Channel
All Behavior upon
CPU STOP
Set substitute
value/ maintain last
value/no current or
voltage
No current or
voltage
Channel
All Substitute value* 0/1 0 Channel
* Substitute values are current or voltage values that are output upon STOP of the master CPU by the
module with analog outputs to the process.
