ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
7.7 EM 141 DI 4 DC 24V expansion module
(6ES7 141-1BD31-0XA0)
Features
The EM 141 DI 4  DC 24V expansion module; order number
6ES7 141-1BD31-0XA0 has the following features:
 4 digital inputs
 Rated input voltage of 24 VDC
 Suitable for switches and proximity switches (BEROs)
Pinout of the sockets for DI
The following table shows the pinout of the four sockets used to connect the digital
inputs. You can find the wiring of the connector in Section 4.4.3. You can find the
layout of the sockets in Appendix C.
Table 7-18 Pinout of the sockets for 4-channel digital inputs
Pin Assignment
of socket X1
Assignment
of socket X2
Assignment
of socket X3
Assignment
of socket X4
Front view of
socket
1 Sensor supply output 1L+
2 Input signal,
channel 1*
– Input signal,
channel 3*
–
2
3 Chassis ground, power supply
1
2
3
5
4 Input signal,
channel 0
Input signal,
channel 1*
Input signal,
channel 2
Input signal,
channel 3*
4
5 PE
* Note: Channel 1 and channel 3 are only allowed to be used at one socket (X1/X2 or X3/X4).
Covering up unused connections
You must seal off any connections which are not required with M12 screw caps, in
order to ensure that the degree of protection (IP 65, IP 66 or IP 67) is achieved.
