Commissioning and Diagnostics
5-12
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Starting up the ET 200X-DESINA
”RUN” LED comes on. Inputs
and outputs enabled; data trans-
fer possible between the ET
200X-DESINA and DP master.
Switch off non-switched
load voltage for
ET 200X-DESINA
Switch on non-switched load
voltage for ET 200X-DESINA
Yes
No
ET 200X-DESINA sets out-
puts to ”0” and applies set
PROFIBUS address
ET 200X-DESINA receives
configuration data from DP
master
Does configuration
data agree with real in-
stallation?
Match configuration data to
configuration or vice versa
”DC 24V-NS” LED comes on
SF red
RUN flashing green
Figure 5-5 Start-up of the ET 200X-DESINA
