Dimesioned Drawings and Pinouts
C-5
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
53.5 28.25
86.5
60
178
53
Figure C-4 Dimensioned drawing of EM 141 (high design),
EM 142 DO 8 x DC 24V/1.2A and EM 143-DESINA expansion modules
C.3 Dimensioned drawing – pneumatic module
EM 148-P DI 4 y DC 24 V/DO 2 y P
The dimensioned drawing of the pneumatic module is shown below. You have to
add the length and bending radius of the tubing to the specified overall height.
173
60
87
53.5 28.25
88
Figure C-5 Dimensioned drawing of the pneumatic module
