Technical Specifications
7-60
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Effect of the supply voltage and the operating mode
The output values of the module are dependent on the supply voltage for the
electronics/sensors and on the operating status of the PLC (CPU of the DP
master).
Table 7-29 Dependencies of digital output values on the operating status of the PLC (CPU of DP master)
and L + supply voltage
Operating mode
of the PLC (CPU
of the DP master)
Supply voltage L + to
ET 200X
Output value of expansion module
Power RUN L + applied PLC value
on
L + not applied 0 V
Power STOP L + applied Substitute value/last value (default:0 V)
on
L + not applied 0 V
Power
off
– L + applied After current operation: substitute value/last value
(default: 0 V)
Upon commissioning the DP slave: 0 V
L + not applied 0 V
Supply voltage on/off
A failure of the supply voltage to the electronics/sensors on the ET 200X is always
displayed by the ”ON” LED on the basic module and also entered in the diagnostic
data area of the basic module.
