Siemens SIMATIC ET 200X - Technical Specifications of the 5-Core Cable

Wiring
4-13
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Table 4-3 Technical specifications of the 5-core cable
Parameters Value
Type of cable
 With PVC sheath
 With PUR sheath, suitable for drum
use
02Y(ST)C 120.65/2.56-150 LI
LIY-J Y 310.75 VI KF30
02Y(ST)C 120.65/2.56-150 LI
LIY-J Y 11 310.75 PETROL
Cable structure
a) Core LIY 0.75/1.70
Copper strands 24  0.2 BLW
Polyvinylchloride sheathing (PVC)
Section thickness
b) Core 02Y 0.65/2.56 LI
Copper strands 19  0.13 BLW
Celled polyethylene sheathing
c) Pair LI02Y(ST)C 120.25/2.6
2 cores to b) RD, GN braided
Aluminum coated foil, overlapped
Braided shield made of Cu wires
Outer sheath
∅ 1.23 mm
∅ 1.7 mm
approx. 0.23 mm
∅ 0.65 mm
∅ 2.56 mm
0.15 mm ∅ VZN
approx. 65 %
Core
1 bundle to c), 3 cores to a) GNYE, BK,
BL
Filler
Plastic foil, overlapped ∅ 7.9 mm
Sheath
Section thickness
PVC or PUR
approx. 0.8 mm
Outside diameter (9.5 0.5) mm
Permissible minimum bending radius
 recurrent bending
 once-only bending
 70 mm
 35 mm
Operating temperature –30 °C to +60 °C
Weight approx. 105 kg/km
