Installation
3-2
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
3.1 Installing/deinstalling the ET 200X
Installation Position
The ET 200X with no motor starters or frequency converters can be installed in
any position.
An ET 200X with motor starters or frequency converters can be installed on a
vertical wall in the following positions:
ET 200X tilted up to 22.5 to the front or the rear, and/or
ET 200X rotated up to 90 to the right or the left.
DIN rail
As a preference, the ET 200X modules must be installed on a DIN rail. Five types
are available (see Table 3-1 and Figures 3-1 and 3-2).
Table 3-1 DIN rails for installing an ET 200X
Description Order No.
DIN rail, narrow, length 400 mm
for ET 200X electronic module
6ES7 194-1GA00-0XA0
DIN rail, narrow, length 640 mm
for ET 200X electronic module
6ES7 194-1GA10-0XA0
DIN rail, narrow, length 2000 mm
for ET 200X electronic module
6ES7 194-1GA20-0XA0
DIN rail, wide, length 520 mm
for ET 200X electronic module and motor
starter/frequency converter/pneumatic interface
module
6ES7 194-1GB00-0XA0
DIN rail, wide, length 1000 mm
for ET 200X electronic module and motor
starter/frequency converter/pneumatic interface
module
6ES7 194-1GB10-0XA0
Screws with washer assemblies (100 screws M5 x
20, crossed recessed head with washer) for fitting
ET 200X modules onto DIN rail
6ES7 194-1KC00-0XA0
