General Technical Specifications
6-5
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Sine-shaped interference
The following table shows the electromagnetic compatibility of the ET 200X
distributed I/O device with regard to sine-shaped interference.
RF radiation in accordance with IEC 61000-4-3
Electromagnetic RF field
RF coupling in
accordance with
Amplitude-modulated Pulse-modulated
IEC 61000-4-6
80 to 1000 MHz 900 MHz 5 MHz 0.15 to 80 MHz
10 V/m 10 V
rms
unmodulated
80 % AM (1 kHz) 50 % ED 80 % AM (1 kHz)
200 Hz repetition frequency 150 W source impedance
Emission of radio interference
Emitted interference of electromagnetic fields in accordance with EN 55011: limit
value class A, group 1 (measured at a distance of 30 m).
Frequency Emitted interference
From 30 to 230 MHz < 30 dB (mV/m)Q
From 230 to 1000 MHz < 37 dB (mV/m)Q
