Technical Specifications
7-11
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Dimensions and weight
Dimensions
W H D (mm)
175 180 110
Weight Approx. 650 g
Module-specific data
Baud rate 9.6/19.2/45.45/93.75/1
87.5/500 kbps
1.5/3/6/12 Mbps
Bus protocol PROFIBUS-DP
FREEZE compatibility Yes
SYNC compatibility Yes
Number of channels 8 digital inputs
Cable length
Unshielded Max. 30 m
Manufacturer identification 80D2
H
Voltages, currents, potentials
Non-switched rated load
voltage (NS)
Max. perm. power
input from load
Reverse polarity
protection
Short circuit protection
24 VDC
Up to 40 C 10 A;
Up to 55 C 8 A
No
No
Switched rated load
voltage (NS)
Max. perm. power
input from load
Reverse polarity
protection
24 VDC
Up to 40 C 10 A;
Up to 55 C 8 A
No
Maximum number of in-
puts driven simulta-
neously
all installed positions
to max. 55 C
8
Electrical isolation
Between channels and
backplane bus
No
Between channels No
Between load voltages No
Between load voltage
and all other circuitry
No
Between
PROFIBUS-DP and all
other circuitry
Yes
Permissible potential diffe-
rence
Between different
circuits
75 VDC, 60 VAC
Insulation tested with 500 VDC
Power input
From backplane bus
(1L+)
Max. 180 mA
Power loss of module Typ. 3.5 W
Status, alarms, diagnostics
Status display Green LED per chan-
nel
Alarms Diagnostic interrupt
Diagnostic functions Configurable
Group error Red LED (SF)
Status indicator Green LED (RUN)
Indicator for
non-switched load
voltage
Green LED
(DC 24V-NS)
Indicator for switched
load voltage
Green LED
(DC 24V-S)
Reading diagnostic
information
Possible
Sensor supply outputs
Outputs
Output current*
Short circuit protection
8
Up to 40 C max. 1A;
to 55 C max. 0.8A
Yes, electronic
