Technical Specifications
7-17
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Sensor supply outputs
Outputs
Output current*
Short-circuit protection
8
Up to 40 C max. 1A;
to 55 C max. 0.8A
Yes, electronic
Sensor selection data
Input voltage
Rated value
With signal ”1”
With signal ”0”
24 VDC
13 to 30 V
– 3 to 5 V
Input current
With signal ”1” Typ. 10 mA
Input delay (parameteriza-
ble)
At ”0” to ”1” and at ”1”
to ”0”
Typ. 0.5 ms
Typ. 3 ms
Typ. 15 ms
Typ. 20 ms
Input characteristic To IEC 61131, Type 2
Connection of two-wire
BEROs
Permissible
closed-circuit current
Possible
Max. 1.5 mA **
* Please note the total current per ET 200X.
** The required closed-circuit current for wire break
detection is 0.6 mA < I < 1.5 mA
