Technical Specifications
7-32
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Dimensions and Weight
Dimensions
W H D (mm)
175 180 110
Weight Approx. 650 g
Module-specific data
Baud rate 9.6/19.2/45.45/93.75/
187.5/500 kbps
1.5/3/6/12 Mbps
Bus protocol PROFIBUS-DP
FREEZE compatibility Yes
SYNC compatibility Yes
Number of channels 8 digital inputs and
outputs
8 functional
inputs (diagnostics
inputs or inputs with
NC functionality)
Cable length
Unshielded Max. 30 m
Manufacturer identification 809A
H
Voltages, currents, potentials
Non-switched rated load
voltage (NS)
Max. perm. power input
from load
Reverse polarity
protection
Short-circuit protection
24 VDC
Up to 40 C 10 A;
Up to 55 C 8 A
No
No
Switched rated load voltage
(NS)
Max. perm. power input
from load
Reverse polarity
protection
24 VDC
Up to 40 C 10 A;
Up to 55 C 8 A
No
Maximum number of inputs
driven simultaneously
all installed positions
max. 55 C
8
Aggregate current of out-
puts
All installation positions
To 20 C
To 50 C
To 55 C
Max. 10 A
Max. 6 A
Max. 5 A
Electrical isolation
Between channels and
backplane bus
No
Between channels No
Between load voltages No
Between load voltage
and all other circuitry
No
Between
PROFIBUS-DP and all
other circuitry
Yes
Permissible potential diffe-
rence
Between different
circuits
75 VDC, 60 VAC
Insulation tested with 500 VDC
Power loss of module Typ. 3.5 W
Status, alarms, diagnostics
Status display Yellow LED
per channel
Indicator for functional input Yellow/red LED
per channel
Alarms Diagnostic interrupt
Diagnostic functions Configurable
Group error Red LED (SF)
Status indicator Green LED (RUN)
Indicator for
non-switched load
voltage
Green LED
(DC 24V-NS)
Indicator for switched
load voltage
Green LED
(DC 24V-S)
Reading diagnostic
information
Possible
Sensor supply outputs
Outputs
Output current
Short-circuit protection
8
Up to 40 C
max. 1 A;
Up to 55 C
max. 0.8 A
Yes, electronic
