Technical Specifications
7-39
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Sensor selection data
Input voltage
Rated value
With signal ”1”
With signal ”0”
24 VDC
13 to 30 V
– 3 to 5 V
Input current
With signal ”1” typ. 7 mA
Input delay
From ”0” to ”1”
From ”1” to ”0”
1.2 to 4.8 ms
1.2 to 4.8 ms
Input characteristic To IEC 61131,
Type 1
Connection of two-wire
BEROs
Permissible
closed-circuit current
Possible
Max. 1.5 mA
* Please note the total current per ET 200X.
7.9 EM 141 DI 8 DC 24V DIAG expansion module
(6ES7 141-1BF30-0XB0)
Hardware
The expansion module can be used together with the following basic modules:
BM 141 DI 8DC 24V, 6ES7 141-1BF01-0XB0, from product version 05
6ES7 141-1BF11-0XB0, from product version 01
6ES7 141-1BF12-0XB0, from product version 01
BM 141 DI 8DC 24V ECOFAST,
6ES7 141-1BF00-0AB0, from product version 01
6ES7 141-1BF01-0AB0, from product version 01
BM 141 DI 8DC 24V ECOFAST DIAG,
6ES7 141-1BF40-0AB0, from product version 01
BM 142 DO 4DC 24V/2A, 6ES7 142-1BD11-0XB0, from product version 05
6ES7 142-1BD21-0XB0, from product version 01
6ES7 142-1BD22-0XB0, from product version 01
BM 143-DESINA FO, 6ES7 143-1BF00-0XB0, from product version 01
BM 143-DESINA RS485, 6ES7 143-1BF00-0AB0, from product version 01
BM 147/CPU, 6ES7 147-1AA00-0XB0, from product version 01
