Technical Specifications
7-49
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Parameters
The following table summarizes the parameters that you can set for the expansion
module.
Table 7-24 Parameters of the EM 141 DI 8 DC 24V DIAG
Parameters
Range Default Area affected
Input delay
1
0.5 ms/ 3 ms/ 15 ms/
20 ms
3 ms Module
Diagnosis: short circuit
to M
Yes/no No Channel
Diagnosis: wire break Yes/no No Channel
Diagnostic interrupt Yes/no No Module
Hardware interrupt Yes/no No Module
Hardware interrupt on
rising edge
2
Yes/no No Channel
Hardware interrupt on
falling edge
2
Yes/no No Channel
1
The input delay applies at ”0” to ”1” and at ”1” to ”0”.
2
These parameters can only be set if you enable the hardware interrupt parameter.
