Technical Specifications
7-64
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Dimensions and weight
Dimensions
W H D (mm)
87 180 55
Weight Approx. 350 g
Module-specific data
Number of outputs 8
Cable length
Unshielded Max. 30 m
Voltages, currents, potentials
Aggregate current of out-
puts
All installation positions
to 20 C
to 50 C
max. 7 A
max. 5 A
Electrical isolation
Between backplane bus
and all other circuit
components
Between channels
Yes
No
Permissible potential diffe-
rence
Between different
circuits
75 VDC, 60 VAC
Insulation tested with 500 VDC
Power input
From backplane bus
(1L+)
From load voltage 2L+
(without load)
Max. 35 mA
Max. 12 mA
Power loss of module Typ. 1.5 W
Status, alarms, diagnostics
Status display Green LED per
channel
Alarms None
Actuator selection data
Output voltage
With signal ”1”
Output current
With signal ”1”
Rated value
Permissible range
With signal ”0” (residual
current)
min. 2L+ (–1.2 V)
1.2 A
5 mA to 13 A
Max. 0.5 mA
Load resistance range 21 W to 4 kW
Lamp load Max. 10 W
Parallel connection of two
outputs
For redundant control of
load
For performance
improvement
Possible
(outputs in same
group only)
Not possible
Driving a digital input Possible
Switching frequency
Resistive load
Inductive load to
IEC 947-5-1, DC13
Lamp load
Max. 100 Hz
Max. 0.5 Hz
Max. 1 Hz
Limitation (internal) of vol-
tage induced on circuit in-
terruption
Typ. 2L+ (– 47 V)
Short-circuit protection for
output
Response threshold
Yes, electronic
Typ. 1.8 A
