Technical Specifications
7-72
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Dimensions and weight
Dimensions
W H D (mm)
87 173 88
Weight Approx. 500 g
Module-specific data
Number of inputs 4 (electrical)
Number of outputs 4 (pneumatic)
Length of cable (inputs)
Unshielded Max. 30 m
Voltages, currents, potentials
Maximum number of inputs
driven simultaneously
All installation positions
To 55 C
4
Permissible potential diffe-
rence
Between different
circuits
75 VDC, 60 VAC
Insulation tested with 500 VDC
Power input
From backplane bus
(1L+)
From 2L+ load voltage
(incl. valves)
Max. 40 mA
Max. 130 mA
Power loss of module Typ. 3 W
Status, alarms, diagnostics
Status display Green LED per
channel
Green LED per
valve
Alarms None
Sensor supply outputs
Outputs
Output current*
Short-circuit protection
2
Up to 40 C
max. 0.9A;
Up to 55 C
max. 0.7A
Yes, electronic
Sensor selection data
Input voltage
Rated value
With signal ”1”
With signal ”0”
24 VDC
13 to 30 V
– 3 to 5 V
Input current
With signal ”1” Typ. 7 mA
Input delay
From ”0” to ”1”
From ”1” to ”0”
1.2 to 4.8 ms
1.2 to 4.8 ms
Input characteristic To IEC 61131,
Type 2
Connection of two-wire BE-
ROs
Permissible
closed-circuit current
Possible
Max. 1.5 mA
Valve outlets
Medium Compressed air (for
properties refer to
paragraph below)
Pressure range 3 to 8 bars
Rated flow 300 l/min
Valve switching times
On, change
Off
20 ms
20 ms
Current input per valve 50 mA
* Please note the total current per ET 200X.
Compressed air for valve outlets
You should operate the valves with filtered (40 m m), dried and oil-free compressed
air of Class 5 4 3 in accordance with ISO 8573-1.
Operation with filtered, dried and oiled compressed air of Class 5 4 5 is similarly
possible. For this purpose, use an oil that is included on FESTO’s list of proposed
oils:
