Technical Specifications
7-125
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Dimensions and weight
Dimensions
W H D (mm)
87 110 55
Weight Approx. 250 g
Module-specific data
Number of outputs 2
Cable length
Shielded Max. 30 m
Voltages, currents, potentials
Electrical isolation No
Permissible potential diffe-
rence
Between coil (frame
connection) and
centralized grounding
point (U
ISO
)
0 VAC; DC
Power input
From supply voltage L+
Power loss of the module
Max. 75 mA
Typ. 1.5 W
Analog value formation
Resolution (including over-
range)
11 bits plus sign
Rated value in units:
– SIMATIC S7 format:
– SIMATIC S5 format:
1728
1024
Cycle time (all channels) 1 ms
Settling time
For resistive load
For capacitive load
0.6 ms
6.0 ms
Replacement values can be
applied
No
Interference suppression, error limits
Operational limit (entire
temperature range with re-
ference to output range)
1 %
Basic error (operational limit
at 25 C with reference to
output range)
0.9 %
Temperature error (with re-
ference to output range)
0.01 %/K
Crosstalk between outputs > 45 dB
Linearity error (with refe-
rence to output range)
0.08 %
Repeat accuracy
(steady state at 25 C with
reference to output range)
0.05 %
Output ripple (with refe-
rence to output range,
bandwidth 0 to 50 kHz)
0.05 %
Status, alarms, diagnostics
Alarms Diagnostic interrupt
Diagnostic functions
Group error
Configurable
Red LED (SF)
Actuator selection data
Output range (rated value) –10 to 10 V
Load resistance
With capacitive load
Short circuit protection
Short-circuit current
Min. 1.0 kW
Max. 0.1 mF
Yes
Max. 30 mA
Permissible input voltage
for voltage output (destruc-
tion limit)
15 V
Actuator connection
Two-conductor
connection
Four-conductor
connection
Possible
Possible
