Dimesioned Drawings and Pinouts
C-10
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Note
You must cut the narrow DIN rail (with a length of 2000) to suit your requirements
and drill the mounting holes for M8 screws.
To ensure that all the ET 200X modules have the specified vibration resistance,
the mounting holes should be spaced at even intervals of a maximum 200 mm
after initial spacing of 12 mm.
