Kinematic Transformation (M1)

12.3 TRACYL

Turning, Milling, Nibbling

244 Function Manual, 11/2012, 6FC5397-1CP10-5BA0

Settings for second spindle (milling spindle of the lathe):

● MD30300 IS_ROT_AX[AX4]=1

● MD30310 ROT_IS_MODULO[AX4]=1

● MD30320 DISPLAY_IS_MODULO[AX4]=1

● MD35000 SPIND_ASSIGN_TO_MACHAX[AX4]=2

● SD43300 ASSIGN_FEED_PER_REV_SOURCE[AX4]=0

Note

A special handling of milling tools on lathes with respect to length compensation is

possible.

See Chapter "Tool: Compensation and Monitoring (W1)"
