Siemens SINUMERIK 802D sl - Page 39

Various Interface Signals (A2)
1.6 NC services
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
39
Variable r0079[1]
CO: Torque setpoint at the output of the speed controller (before clock cycle interpolation)
[Nm]
Index: [1] = Smoothed with p0045
Variable r0079[0...1] [r]
VB120x1000 11
VB120x1001 No. of drive module
VW120x1002 -
VW120x1004 -
VD120x1008 -
VD120x3004 Read: Data from NCK variable x (data type of the variables: REAL)
Variable r0081
CO: Torque utilization in percent
Variable r0081 [r]
VB120x1000 12
VB120x1001 No. of drive module
VW120x1002 -
VW120x1004 -
VD120x1008 -
VD120x3004 Read: Data from NCK variable x (data type of the variables: REAL)
Variable r0082[1]
CO: Active power actual value [kW]
Index: [1] = Smoothed with p0045
Variable r0082[0…2] [r]
VB120x1000 13
VB120x1001 No. of drive module
VW120x1002 -
VW120x1004 -
VD120x1008 -
VD120x3004 Read: Data from NCK variable x (data type of the variables: REAL)
