Various Interface Signals (A2)
1.6 NC services
Turning, Milling, Nibbling
38 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
Variable rpa
R parameters
Variable rpa [r/w]
VB120x1000 5
VB120x1001 -
VW120x1002 R number + 1
VW120x1004 -
VD120x1008 Write: Data to NCK variable x (data type of the variables: REAL)
VD120x3004 Read: Data from NCK variable x (data type of the variables: REAL)
Variable actLineNumber
Line number of the current NC block:
● 0: Prior to program start
● -1: Not available due to error
● -2: Not available due to
DISPLOF
Variable actLineNumber [r]
VB120x1000 6
VB120x1001 -
VW120x1002 -
VW120x1004 -
VD120x1008 -
VD120x3004 Read: Data from NCK variable x (data type of the variables: DINT)
Variable r0078[1]
CO: Current actual value, torque-generating [Arms]
Index: [1] = Smoothed with p0045
Variable r0078[0...1] [r]
VB120x1000 10
VB120x1001 No. of drive module
VW120x1002 -
VW120x1004 -
VD120x1008 -
VD120x3004 Read: Data from NCK variable x (data type of the variables: REAL)
