Siemens SINUMERIK 840D Simodrive 611 digital User Manual

6 Pro
g
rammin
g
the control
6
03/2006
6.9 Axes and spindles
6-117
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
MD 35110: GEAR_STEP_MAX_VELO [0,A1] = 500 (not used for spindle)
MD 35110: GEAR_STEP_MAX_VELO [1,A1] = 500
(n
max
for gear step change, gear step 1)
MD 35110: GEAR_STEP_MAX_VELO [2,A1] = 1000
(n
max
for gear step change, gear step 2)
6.9.14 Spindle configuration
Setpoints: MD 30100: CTRLOUT_SEGMENT_NR
MD 30110: CTRLOUT_MODULE_NR
MD 30120: CTRLOUT_NR
MD 30130: CTROUT_TYPE
Actual values MD 30210: ENC_SEGMENT_NR
MD 30220: ENC_MODULE_NR
MD 30230: ENC_INPUT_NR
MD 30240: ENC_TYPE
Note
Further information about the spindle configuration can be found in the “Drive
configuration” section above.
Example
Machine data for
setpoint and actual
values

Siemens SINUMERIK 840D Simodrive 611 digital Specifications

General

Type	CNC Control
Drive System	Simodrive 611 digital
Control System	SINUMERIK 840D
Application	Machine tools (milling, turning, grinding, etc.)
Compatibility	SINUMERIK 840D
