6.9 Axes and spindles
6-85
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
6.9.3 Programming axis-specific setpoint/actual values
A setpoint value channel (i.e. a logical drive number) and at least one actual
value channel must be assigned to each axis/spindle for the position measuring
system. An optional second channel may be specified for a second position
measuring system.
The motor measuring system is always used for the speed regulation (X411).
The following fixed assignment is used between the motor connection and the
motor measuring system connection: The motor and motor measuring system
must always be connected to the same module.
Assigning the setpoint channel (axis-specific)
MD Meaning Input for example 1 (see Fig. 6-6)
MD 30110:
CTRLOUT_MODULE_NR
Assignment of a logical drive no.
to setpoint channel
X1=“1” Slot 2
Y1=“2” Slot 3
Z1=“3” Slot 4
C1=“4” Slot 1
MD 30130: CTRLOUT_TYPE Setpoint channel exists “1”
Assignment actual value channel (axis-specific)
MD Meaning Input for example 1
MD 30200: NUM_ENCS Number of measuring channels
“1” if there is just one position
measuring system
(“2” if there are two position mea-
suring systems)
X1=“1”
Y1=“1”
Z1=“1”
C1=“1”
MD 30240: ENC_TYPE[0] Encoder type
“1” for incremental encoders
(“4” for absolute encoders with
EnDat interface)
X1=“1”
Y1=“1”
Z1=“1”
C1=“1”
MD 30220:
ENC_MODULE_NR[0]
Allocation of a logical drive no. to
the actual value channel for posi-
tion measuring system 1
X1=“1” Slot 2
Y1=“2” Slot 3
Z1=“3” Slot 4
C1=“4” Slot 1
MD 30220:
ENC_MODULE_NR[1]
Allocation of a logical drive no. to
the actual value channel for posi-
tion measuring system 2
Position measuring system 2 is not used
MD 30230: ENC_INPUT_NR[0] Allocation for position measuring
system 1
“1” for motor measuring system
“2” for direct measuring system
X1=“1”
Y1=“1”
Z1=“2”
C1=“1”
MD 30230: ENC_INPUT_NR[1] Allocation for position measuring
system 2
“1” for motor measuring system
“2” for direct measuring system
Position measuring system 2 is not used
Assigning the set-
point/actual value
channels
