11
03/2006
11.11Data back-up with VALITEK streamer with the PCU 50
11-255
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
11.11 Data back-up with VALITEK streamer with the PCU 50
Using the VALITEK streamer you can
S back up all data on hard disk C (Back-up all)
S back up the user data (archive format) in directory C:\DH\ARC.DIR (Back-up
User Data)
S restore the data back-up (Restore from Tape)
The VALITEK streamer is connected to the parallel port X8 (25-pin) on the
PCU 50/70 using only the SIEMENS cable 6FC9 344-4xV. No other data
back-up device can be connected since the software is designed to operate
with the VALITEK streamer.
While the HMI is booting (after switching on the control system)
when the message Starting MS DOS appears:
1. Press the 6 key once briefly on the front operating panel keyboard.
The following menu is displayed:
PLEASE SELECT:
1 Install/Update MMC System
2 MMC Configuration Tool
3 DOS Shell
4 Start Windows (Service Mode)
5 MMC System Check
6 Reboot System (Warmboot)
7 Back-up / Restore
8 Start PC Link
9 End (Load MMC)
Your Choice [1,2,3,4,5,6,7,8]?
2. Press key 7.
The system asks you to enter a password:
passwd:
3. Enter a password for level 0 to 2.
– System
– Manufacturer
– Service
The following menu is displayed:
What can you
back up?
Streamer
connection
Operation
11 Data Back-U
