Siemens SINUMERIK 840D Simodrive 611 digital User Manual

11
03/2006
11.7 Data output
11-240
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
DIAGNOSIS
MachDat/FDD
MachDat/MSD
11.7.2 Outputting the NC data via V24
By NC data we mean all data that is located in the SRAM of the NC (without
part programs and cycles).
The following data is stored in the “NC active data” directory:
S NC machine data (MD11210 UPLOAD_MD_CHANGES_ONLY =1)
S Option data
S Setting data
S Tool/machine data
S Work offset
S R parameters
S Global user data
S Protection areas
S Compensation data
– Measuring system error offset (EEC)
– Beam sag/angular compensation (CEC)
– Quadrant error offset (QEC)
The file header starts with “%_N” and ends with “_INI”. If you are outputting all
the global user data, the file header is as follows: %_N_COMPLETE_GUD_INI.
In the display NC active data the “central section” of the file header is displayed,
depending on the current cursor position. Look to the right of “Program/Data”.
Outputting the measuring system error offset data. If you wish to output the EEC
compensation data via RS-232 you can proceed in two ways:
1. Read out EEC data in their entirety (all axes).
2. Axis-specific output of EEC data.
NC data
Structure of the
file header
Example 1
11 Data Back-U
p
