10.6 Graphical display
10-195
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
These soft keys are used to display a vertical or horizontal line representing the
abscissa or ordinate in the selected diagram. The associated coordinates are
also output. The soft key X marker or Y marker must be selected again in order
to deselect the markers. The markers are moved by means of the cursor keys.
This soft key is used to toggle between the individual representations and the
double graph. You can then use the “Print graph” soft key to store the graph
(Print to file) or output it at the selected printer.
Individual traces can be displayed and hidden in graph 1 and graph 2. The soft
key always takes effect in the currently selected window.
The “Start” soft key is used to start a new measurement.
10.6.1 Associated conditions for gantry axes
SIMODRIVE 611 digital drives: Only one function generator or one measuring
function can be activated on a multiple module, which means that the new func-
tionality is available if the gantry axes are on different modules.
Reference material: /FB3/ G1, Description of the special functions
Gantry axes
X marker and
Y marker Y zoom
and full screen
soft keys
Graph...
Trace...
Start
From software
version 5.1
10 Drive O
p
timization
