8.3 Syntax for alarm text files
The following alarm numbers are available for the cycle, compile cycle and PLC
alarms:
Table 8-1 Alarm numbers for cycle, compile cycle and PLC alarms
Number range Designation Effect Clear
60000–60999 Cycle alarms
(Siemens)
Display, lock NCK start Reset
61000–61999
(Siemens)
Display, lock NCK start,
motion stopped
Reset
62000–62999 Display Cancel
63000–64999 Reserved
65000–65999 Cycle alarms
()
Display, lock NCK start Reset
66000–66999
(user)
Display, lock NCK start,
motion stopped
Reset
67000–67999 Display Cancel
68000–69000 Reserved
70000–79999 Compile cycle alarms
400000–499999 PLC alarms general
500000–599999 PLC alarms for channel
600000–699999 PLC alarms for axis and
spindle
700000–799999 PLC alarms for user
800000–899999 PLC alarms for sequence
cascades/graphs
The range of numbers given in the list is not available with every number, see
Reference material: /FB1/ P3, PLC basic program powerline,
/LIS1/ Lists
Table 8-2 Structure of text file for cycle alarm texts
Alarm number Display Help ID Text or alarm number
60100 1 0 “No D number %1 is programmed”
60101 1 0 60100
... ... ... ...
65202 0 1 “Axis %2 in channel %1 is still moving”
// Alarm text file for cycles in German
List of alarm numbers
Alarm numbers
Format of the text
file for cycle alarm
texts
Alarm number
