8
03/2006
8.2 Alarm text files for HMI Advanced
8-166
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
The language for the user alarm texts is assigned via the name of the text file.
The appropriate code and the extension .com are added to the user file name
entered in mbdde.ini:
Language Code
German gr
English uk
French fr
Italian it
Spanish sp
myplc_gr.com File for German PLC alarm texts
mynck_uk.com File for English NCK alarm texts
Note
Changes to alarm texts do not take effect until the HMI has powered up again.
When you create the text files, make sure that the date and time are set cor-
rectly on the PC, otherwise the user texts may not be displayed on screen.
File with German user texts, PLC:
myplc_gr.com
700000 0 0 “DB2.DBX180.0 set”
700001 0 0 “No lubrication pressure”
The maximum length of an alarm text is 110 characters for a 2-line display.
Language-specific
nature of the alarm
texts
Example
Example for HMI
Advanced
8 Alarm and messa
e texts
