11.5.1 Standard system start-up
5. HMI interface configuration (see above, punched tape format unchecked)
6. Start PCIN data transmission program (“Data In”) on PC/PG.
7. If “Start-up data” is selected via the HMI (HMI “Services” area, data output
“Data Out”), the NCK and PLC areas are suggested when you press the
“Input” key.
8. First select “NCK” (”NCK” is suggested as the name of the archive file) and
start reading the data (“Start” soft key). Follow exactly the same procedure
for the “PLC” data set.
5. HMI interface configuration (see above: Check punched tape format, apart
from for drive data)
6. Start the PCIN data transfer program (“Data In”) on the PC/PG.Enter file
names.
7. On the HMI, select the data area to be output (HMI “Services” area, data
output “Data Out”):
8. Press the “Data selection” soft key and select the areas to be read. The
“NC-active data” area, for example, contains the following data:
– Machine data
– Setting data
– Option data
– Global and local user data
– Tool and magazine data
– Protection areas
– R parameters
– Zero offsets
– Drive data
– Compensation data
– Display machine data
– Workpieces, global part programs/subroutines
– Standard and user cycles
– Definitions and macros
When the areas are output, the internal area identifier used in each case
appears on the top line of the display.
9. Start reading the data (“Start” soft key) and acknowledge any input prompts.
Standard system
start-up
(data back-up)
Archiving by area
