11
03/2006
11.4 Data back-up via PG/PC
11-229
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
11.2 Data back-up via HMI Embedded
With a PCU 20, the data is backed up via the user interface of the HMI Embed-
ded software.
Details of the procedure can be found in the following documentation:
reference material: /IAM/ IM2, HMI EmbeddedStart-up Guide
/BEM/ Operator’s Guide, HMI Embedded
11.3 Data back-up via HMI Advanced
With a PCU 50/50.3/70 , the data is backed up via the user interface of the HMI
Advanced software.
Details of the procedure can be found in the following documentation:
Reference material: /IAM/ IM4, HMI AdvancedStart-up Guide
/BAD/ Operator’s Guide, HMI Advanced
11.4 Data back-up via PG/PC
The following data can be backed up via the RS-232 interface:
S Standard system start-up: with selection options for the following areas:
– NCK (complete)
– PLC (complete)
– HMI (with option of saving only partial areas of the HMI data)
S Archiving by area: Backing up or reloading of individual data areas (“Data
in”, “Data out” and “Data selection” soft keys)
These texts are parts of the front operating panel system software. They must
be reloaded after hardware component replacement or software upgrading. The
messages must be in the correct format (see chapter 13, “Upgrading PCU 20
software”). The texts cannot be read out of the control.
Via RS-232
Error and operator
message texts and
cycle alarm texts
11 Data Back-U
