11
03/2006
11.1 General
11-228
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
You will need the following accessories in order to back up the data:
S PCIN data transmission program for PG/PC
S V24 cable 6FX2002-1AA01-0BF0
Reference material: /Z/ Catalog NC Z (Accessories)
S PG or PC (DOS)
_N_ Area Unit _ Type
S The area specifies which data are to be backed up or retrieved (general,
channel-specific or axis-specific).
S The unit defines the channel, the axis or the TOA area. The unit is omitted if
the entire area has been selected.
S The type determines the type of data. For a data back-up, the file name are
generated and output automatically.
Areas
NC general NC-specific data
CH channel-specific data (unit corresponds to the channel number)
AX axis-specific data (unit corresponds to the number of the
machine axis)
TO tool data
COMPLETE all the data in an area
INITIAL data for all areas (_N_INITIAL_INI)
Types
TEA machine data
SEA setting data
OPT option data
TOA tool data
UFR user input frames: variable NPV, rotations, etc.
EEC measuring system error offset
CEC sag/angularity compensation
QEC quadrant error offset
PRO protection area
RPA R parameters
GUD Global user data
INI general initialization program (all the data for the active filter system)
_N_COMPLETE_TEA archiving of all machine data
_N_AX_TEA archiving of all axis machine data
_N_CH1_TEA archiving of the machine data for channel 1
_N_CH1_GUD archiving of the machine data for channel 1
_N_INITIAL_INI archiving of all the data in the active file system
Required
accessories
Structure of the
file names
Examples
11 Data Back-U
