11
03/2006
11.7 Data output
11-243
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
1. Press the “Standard start-up” soft key.
2. Simply select “PLC”.
3. Press the “Archive” soft key.
4. The display is changed and the job log displayed. The “PLC.ARC” file is
created.
5. If the “Job finished” message appears, then press the “Data out” soft key.
6. Select “PLC.ARC” from the “Archive” directory and press the “Interface” soft
key.
7. Make the following settings for V24 with archive format: “Binary format (PC
format)”.
Press “OK”.
8. Now press the “V24” soft key.
Press the “OK” soft key to start outputting the data.
11.7.4 Outputting the HMI data via V24
With the HMI, the display machine data (MD 9000, ...) should be backed up via
the file functions in the “Start-up” area. This machine data is located in the HMI
Advanced RAM, in the “Diagnostics” –> “MachDat” –> “Operating panel” direc-
tory. The file name assigned when the data were being stored is displayed in
the directory.
To output the display machine data, place the cursor on the desired file, then
press the “V24” soft key and press the “OK” soft key to confirm. The display
machine data can be output in punched tape format.
The “Definitions” directory contains the definitions for the macros and global
user data. These are, for example:
S SMAC.DEF (%_N_SMAC_DEF)
S MMAC.DEF (%_N_MMAC_DEF)
S UMAC.DEF (%_N_UMAC_DEF)
S SDUD.DEF (%_N_SGUD_DEF)
S MGUD.DEF (%_N_MGUD_DEF)
S UGUD.DEF (%_N_UGUD_DEF)
The definitions can be output via the V24 interface.
Example of GUD data:
Define OTTO as String
Define HANS as bool
Define NAME as char
When installing, the definitions must be read in before the INITIAL_INI file. Only
when the definitions are known to the NC can the actual user data be read in.
Procedure
Display machine
data
Definitions
11 Data Back-U
