12
12-265
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Replacing Software and Hardware
12.1 Software update
Note
Sequence for updating software during start-up or software replacement
1. Upgrade HMI
2. Upgrade NCK software
Please note the information in the ReadMe file sent with the ToolBox.
A PCMCIA card is used for the NCU. On the outside, this looks just like the
card with the HMI software, so it is easy to confuse the two. To help distinguish
between the two, the PCMCIA card
S for the NCU is called the “NC card” below and
S the one for the HMI is called the “PC card”.
Every time the software is supplied, the ToolBox contains a ReadMe file that
describes the latest control upgrade.
Naming
convention
for the
PCMCIA card
12
