SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
The associated device/system must only be set up and operated in conjunction
with this documentation. A device/system must only be brought into service and
operated by qualified personnel. Qualified personnel as specified in the safety
instructions in this documentation are people who are authorized to bring into
service, earth and identify devices, systems and power circuits in accordance
with the recognized safety standards.
Please note the following points:
!
Warning
The device must only be used for the purposes described in the catalog and in
the technical description, and then only in conjunction with non-Siemens devi-
ces and components that are recommended or approved by Siemens. Correct
and safe operation of the product requires it to have been transported, stored,
installed and assembled correctly and carefully operated and maintained.
Note
The “Note” symbol is displayed in this document to draw your attention to infor-
mation relevant to the subject.
Technical information
The following notations and abbreviations are used in this documentation:
S PLC interface signals –> NST “signal name” (signal data)
Examples:
– IS “MMC CPU1 ready” (DB10, DBX108.2), i.e. the signal is stored in data
block 10, data byte 108, bit 2.
– IS “Feedrate override” (DB31, ... DBB0), i.e. the signals are stored in
data blocks 31 to 38, data block byte 0.
S Machine data –> MD: NUMMER, MD_NAME (German designation)
S Setting data –> SD: NUMMER, SD_NAME (German designation)
S The character “8” means “corresponds to”.
J
Qualified
personnel
Use as prescribed
Further notes
Notations
Preface
