6.12 System settings for power-up, RESET and starting part programs
6-155
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
6.12 System settings for power-up, RESET and starting part
programs
The response of the control changes after the following actions:
S Power-up (POWER-ON),
S Reset/end of part program and
S Start of part program
The following machine data settings affect the above actions:
MD 20110: RESET_MODE_MASK (define the basic control settings
after power-up and reset) and
MD 20112: START_MODE_MASK (define the basic control settings
after start of part program)
Table 6-30 Changing system settings with MD
Status can be changed by MD
Power-up (POWER-ON), RESET_MODE_MASK
RESET/end of part program RESET_MODE_MASK
Start of part program START_MODE_MASK and
RESET_MODE_MASK
Select the required system response.
S after power-up (POWER-ON)
MD 20110: RESET_MODE_MASK, Bit 0 = 0 or 1
Power-up
(POWER-ON)
MD 20110
RESET_MODE_MASK
Bit 0
Bit 0=0
Bit 0=1
– G codes as per MD 20150: GCODE_
RESET_VALUES
– Tool length correction not active
– Transformation not active
– No coupled units active
– No tangential adjustment active
– Non-configured synchronous spindle
coupling is switched off
– G codes as per MD 20150: GCODE_RESET_VALUES
– Tool length correction active as per MD 20120: TOOL_RESET_
VALUE, MD 20121: TOOL_PRESEL_RESET_VALUE and
MD 20130: CUTTING_EDGE_RESET_VALUE
– Transformation active as per MD 20140: TRAFO_RESET_VALUE
– No coupled units active
– No tangential adjustment active
– Non-configured synchronous spindle coupling is switched off
Fig. 6-46 System settings after power-up
Concept
Procedure
