Indicates the input limits. If no range of values is specified, the data type deter-
mines the input limits and the field is identified with “∗∗∗”.
A detailed explanation of the machine data and a list of all the machine and set-
ting data can be found in the following documentation:
Reference material: /LIS1/ Lists
6.3 Protection level concept
In SINUMERIK 840D there is a protection level concept to enable data areas.
Protection levels range from 0 to 7, 0 representing the highest and 7 the lowest
level.
The lock for protection levels
S 0 to 3 is set with a password in the “Start-up”
operating area.
S 4 to 7 is set directly with key switch positions 3 to 0
on the machine control panel (MSTT).
Protection level 4 (key switch position 3) and higher is required to display
machine data.
The appropriate protection level must generally be enabled by means of pass-
word “EVENING” to start up the system.
Table 6-2 Protection level concept with the relevant data areas
Protection level Locked by data areas
0 Password Siemens
1 Password: SUNRISE (default) Machine manufacturer
2 Password: EVENING (default) Commissioning engineer,
Service
3 Password: CUSTOMER (default) End user
4 Key switch position 3 Programmer, machine setter
5 Key switch position 2 Qualified operator
6 Key switch position 1 Trained operator
7 Key switch position 0 Semi-skilled operator
Protection levels 0 to 3 require a password to be entered. The password for
level 0 provides access to all data areas. For protection levels 1 to 3, default
passwords are defined when the system is powered up in start-up mode (NCK
start-up switch in position 1). To guarantee secure access, these default pass-
words MUST be changed once they have been activated. If, for example, the
passwords have been forgotten, then the system must be reinitialized (NCK
general reset). This resets all passwords to the standard of this software
version.
Range of values
Protection levels
Protection levels
0–3
