6.4 Display filter for machine data
6-61
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
6.4 Display filter for machine data
6.4.1 Function
Using the display filter allows the number of machine data items displayed to be
reduced to a specific number, and thus adapted to suit the user’s needs.
All machine data in the following areas:
S General machine data
S Channel-specific machine data
S Axis-specific machine data
S Drive machine data (FDD/MSD)
are assigned to specific groups.
You can tell which group specific machine data belongs to by referring to the
machine data list.
Reference material: /LIS1/ Lists
S Each area has its own group assignment.
S Each machine data in the different areas can be assigned to several groups.
6.4.2 Selecting and setting the display filter
The filter is selected and activated via a list screen which is opened using the
“Display options” vertical soft key in the relevant machine data areas.
The display will vary according to which HMI software you are using. See:
Reference material: /BAD/ HMI Advanced User Guide
/BEM/ HMI Embedded User Guide
If the user’s access rights (password) are not sufficient, then the machine data
is not displayed. If the access rights are sufficient, there is a check to see if any
display filters are active.
Note
You can tell which group specific machine data belongs to by referring to the
machine data list.
Selecting the list
screens
Display criteria
