11.7 Data output
11-239
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
11.7 Data output
11.7.1 Outputting the drive data via V24
Drive data consists of:
S Boot files (MSD.BOT)
S Boot files (FDD.BOT)
S Drive machine data (*.TEA)
Data Directory Name Meaning
Boot file Diagnosis\FDD data VS1.BOT Boot file, 1st axis
Boot file Diagnosis\MSD data HS1.BOT Boot file, 1st spindle
Drive MD FDD DIAGNOSIS\MachDat/FDD *.TEA Drive machine data file for FDD saved
under Start-up/MD/File functions.
Name must be assigned.
Drive MD MSD DIAGNOSIS\MachDat/MSD *.TEA Drive machine data file for MSD
saved under Start-up/MD/File
functions. Name must be assigned.
The boot files are located in directories FDD data and MSD data.
VS2.BOT
VS1.BOT
FDD.data
MSD data (HS1.BOT)
Note
The boot files can only be output as binary files with the V24 “Archive format”
setting. The boot files must be backed up before they are output (“Save boot
files” soft key). The data back-up for the boot files (in binary format) can only be
reloaded to the same software release.
The drive machine data must first be backed up in the “Start-up” –> “Machine
data” –> “File functions” area before these files can be output via the V24.
Drive data
Where are the boot
files located
Drive machine data
