8.3 Syntax for alarm text files
8-169
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Event number
Signal group Signal number
5 x (for channels) 00–03 (inhibits)
11–16 (GEO axes)
21–28 (additional axes)
00–99
60 (for axis and spindle) 01–18 (axis no.) 00–99
70 (for user) 00–09 (user no.) 00–99
80 (status graph alarms) 00–99 (graph group) 00–99 (graph no.)
This number defines the alarm display type:
0: Display on the alarm line
1: Display in a dialog box
8.3.1 Alarm list properties
In addition to the current alarms, the user interface also displays an alarm log
containing all the alarms that have previously occurred in the form of a list. You
can modify the properties of the alarm list in the MBDDE.INI file.
Table 8-4 Sections of the MBDDE.INIfile:
Section Meaning
Alarms General information about the alarm list (e.g. time/date format of
messages)
Text files Path/file of the text lists for the alarms (e.g. MMC=..\dh\mb.dir\alm_
<signal block in the mb dir.)
HelpContext Name and path name of the help files (e.g. File0=hlp\alarm_)
DEFAULTPRIO Priorities of various alarm types (e.g. POWERON=100)
PROTOCOL Properties of the protocol (e.g. File=.\proto.txt <name and path of log
file>)
KEYS Information on keys that can clear alarms (e.g. Cancel+F10 <delete
alarm using the key combination Shift+F10>)
For further details of the file entries, refer to
Reference material: /BN/ HMI Programming Package, Part 1
The settings in this section define the following alarm list properties:
S TimeFormat
Enter the format to be used when outputting the date and time. This corre-
sponds to the CTime::format from the Microsoft Foundation Classes.
Display
“Alarms”
