5.3 CCU controls and displays
Fig. 5-2 below shows the controls and displays on the CCU that are important
for powering on and powering up the SINUMERIK 810D:
S Various errorand status LEDs (H1/H2)
S 7-segment display (H3)
S RESET button (S1)
S NC start-up switch (S3)
S PLC start-up switch (S4)
S PCMCIA slot
. .
7-segment
display (H3)
PCMCIA
slot
Various error
and status LEDs
(H1/H2)
NCK start-up
switch (S3)
PLC start-up
switch (S4)
RESET
button (S1)
Fig. 5-2 SINUMERIK 810D controls and displays on the CCU
A detailed description of the controls and displays can be found in the following
documentation:
Reference material: /PHC/ Device Manual, CCU Configuration
