SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Programming the control
6.1 Machine and setting data
The control is matched to the machine by means of machine and setting data.
The machine data (MD) is classified as follows:
S General machine data
S Channel-specific machine data
S Axis-specific machine data
S Display machine data (machine data for front control panel)
S Machine data for feed drive
S Machine data for main spindle drive
The setting data (SD) is classified as follows:
S General setting data
S Channel-specific data
S Axis-specific setting data
Used to enable options. Option data is supplied with the specific option.
The machine and setting data is divided into the following areas:
Table 6-1 Overview of machine and setting data
Area Designation
from 1000 to 1799 Machine data for SIMODRIVE drives
from 5000 to 6000 Machine data for the hydraulic module
from 9000 to 9999 Display machine data
from 10000 to 18999 General machine data
from 19000 to 19999 Reserved
from 20000 to 28999 Channel-specific machine data
from 29000 to 29999 Reserved
Programming
Machine data
Setting data
Option data
Overview of
machine and
setting data
6
