10
03/2006
10.7 Trace function
10-196
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
10.7 Trace function
A trace represents monitored values and signals over a given time interval.
Servo trace provides functions with a graphical user interface for checking and
monitoring drive/servo signals and statuses.
The trace function offers the following features:
S 4 trace buffers with up to 2048 values each.
S Choice of SERVO, safety integrate and 611D signals (in position control
cycles)
S Trace and trigger signals can be set through absolute addresses and value
masking.
S Different trigger conditions for starting the recording.
Triggering always on trace 1.
S Both pre- and post-triggering.
S Measuring signal display
S Fixed Y scaling can be selected for each trace or automatic scaling
S Marker function can be selected in order to delimit areas of detail for each
trace. Expand function on the time axis (Zoom X).
S Selectively loads and saves the measuring parameters and traces
S Up to 10 signal tracks per trace for bit-coded signals from Safety Integrated
S Options for modifying the trace display and print-out.
Note
The trace function can only be used with HMI Advanced or the Start-up tool. It
is possible to represent bit-coded signals from Safety Integrated on ten tracks
over the measuring interval for HMI Advanced from software version 6.2.
Function
overview
10 Drive O
timization
