Siemens SINUMERIK 840D Simodrive 611 digital - 2 Nd Machine Control Panel

3
03/2006
3.7 2nd machine control panel
3-32
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Connector designation: X10
Connector type: 3-pin Phönix terminal block, straight
Table 3-7 Assignment of connector X10 on interface for customer’s operating panel
X10
Pin Name Type
1 SHIELD VI
2 M24 VI
3 P24 VI
Reference material: /BH/ Device Manual, Operating Components
3.7 2nd machine control panel
SINUMERIK 840D/810D can be used to operate 2 machine control panels. The
2nd MSTT parameters must be set in the basic program parameters at FB1.
Power supply
interface
3 Settin
g
s, MPI/BTSS
