8.2 Alarm text files for HMI Advanced
8-165
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
...
[Text files]
MMC=c:\dh\mb.dir\alm_
NCK=c:\dh\mb.dir\aln_
PLC=c:\dh\mb.dir\alp_
ZYK=c:\dh\mb.dir\alc_
CZYK=c:\dh\mb.dir\alz_
UserHMI=
UserNCK=
UserPLC=c:\dh\mb.dir\myplc_
UserZyk=
UserCZyk=
...
The standard texts are stored in ASCII format in the following files on the hard
disk of the PCU 50/ 50.3/ 70.
HMI C:\dh\mb.dir\alm_XX.com
NCK C:\dh\mb.dir\aln_XX.com
PLC C:\dh\mb.dir\alp_XX.com
ZYK C:\dh\mb.dir\alc_XX.com
CZYK C:\dh\mb.dir\alz_XX.com
In these file names, “XX” stands for the code of the appropriate language.
The standard files should not be changed by the user to store his or her own
error texts. If these files were replaced with new files during a software upgrade
of the HMI, any added or modified user-specific alarms will be lost. The user
should store his own error texts in user files.
The user can replace the error texts contained in the standard files with his own
texts or add new texts. To do this, the additional files must be downloaded to the
c:\dh\mb.dir directory (MBDDE alarm texts) via the Utilities area. The names of
these text files are set in file c:\mmc2\mbdde.ini The “Diagnostics” –> “Start-up”
–>“HMI” area contains an editor for this purpose.
Sample configurations for two additional user files (texts for PLC alarms, modi-
fied alarm texts NCK) in the MBDDE.INIfile
...
User HMI =
User NCK = C:\dh\mb.dir\mynck_
User PLC = C:\dh\mb.dir\myplc_
User ZYK =
User CZYK =
...
The texts from the user files overwrite standard texts with the same alarm num-
ber. Alarm numbers which do not already exist in the standard texts are added.
An ASCII editor (e.g. the DOS editor “edit”) must be used for editing files.
Standard text files
User files
Editor
