10.7 Trace function
10-201
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Once the parameters have been set, start the measurement by pressing the
Start soft key. Execution is dependent on the condition specified in the
Measuring parameters and “Trigger” input box.
Measurement is terminated after the time specified in the Measuring parame-
ters/“Measuring time” input box has expired or was interrupted by pressing the
Stop soft key.
Results of a canceled measurement cannot be displayed (soft key display).
The end of the measurement is signaled to the user with a suitable message in
the dialog line.
If the user has carried out measurements with values/signals, these are stored
in the measured value buffer and remain valid until they are replaced by measu-
red value files using the file functions or by the measured values supplied when
a measurement was restarted by the NCK.
Start of
measurement
Terminating the
measurement
General
